Blade Jib
Author Last Post
Doug,

We are in 1st place for the current series and the rest of the boats were hoping we'd sit it out due to the wind the other night. It was blowing 20-25 with higher gusts! They are all larger than us. I was a little nervous about the breeze as I had not sailed in that much breeze with the boat. But the boat sailed awesome!!!! We have a short period chop here on the Bay as it's shallow. But the boat plowed through it very well. We were 1st at the top mark and just keep going!

Tell Travis I said hi! I met him a few years ago in Buffalo in the J22 Nationals.  He's sailed down here. Ask him about our chop! He uses my buddy's J70.

Ensign Question: I'm not pointing as high as I think I should. Not sure why. Rig looks ok. Anything that I can check - go over - double ck? Don't have much helm up wind. Boat is usually pretty balanced. Been playing with the jib leads - seemed to help but not sure if that's it. Pretty much the same with either the #1 or #2.

This is my 1st season doing any racing with the boat. Been very impressed with the overall performance. For a 60 YO design it sails soooooo nice! I bought it to have something for my grandkids to sail on!

Thank you. Hope the Class gets this Blade issue resolved soon. I just think it's bad we are showing kids this.

Bob Panico

Yea. The #2 is perfect in that wind and when wind gets over 25 the RC has always ended racing for the day. In Ensign class events I mean.


Sent from Doug phone

Although they are one design doesn't make them the same. The sailmakers only have to conform to the max and min. measurements and after that, they can make different contours making different designs.  Age plays into it also, We did some experimenting years ago with the leads and found further outboard was the best location. Also don't forget about the Working Jib. There are people and fleets out there that use the working jibs instead of the Blades. We want to get this one right for everyone.

Zeke


Hey Doug! Thanks for the clarification on Quantum Sails Rochester.

And there you have! Perfect. Thank you Doug. I'm sure the Class will get it right.


As I stated in my initial comments, we use the blade primarily for instruction. Just want these kids to see what a properly trimmed sail should look like!


On another note: Sailed last night here on the Great South Bay and it blew stink! 20-25 with higher gusts out of the west. Very shifty & a pretty good chop too. Had the #2 on - no reef in the main and the boat sailed awesome! The mainsail trimmer was great all night. This was the biggest breeze I ever sailed the boat in and was VERY impressed with the performance. We sailed PHRF (rating @ 235) and kicked ass! 😁


Bob Panico

No Regrets #1669


Guess I should chime in. Thanks for mostly clearing that up Guy, you're the best. BUT just to clarify, we were not bought buy Quantum Sails. Kris Werner purchased the loft from Steve Haarstick and we are an independent business, Quantum Sails Rochester, and we are a dealer for Quantum Sails.


I am also on the rules committee for the ECA and myself and Benz Faget from North Sails, have both been consulted by the class and, I believe, will be kept in the loop before any final changes are made to the track location and/or sail.


The Blade Jib was not part of the original sail plan and was added in the 80's. Maybe not thought through all the way, I'm not sure. Personally I've actually never sailed on an Ensign with a blade jib. I mostly just race Ensigns and we have never used anything smaller than a #2 at regattas. A quick change to the sizes of the blade jib in the class rules would get it to sheet properly, but there is also the consideration of have the proper athwartship location for best upwind performance, so maybe a change to both is needed.


All the best fellow Ensign sailors and owners,


Doug Burtner

Ensign #740

Quantum Sails Rochester

585-342-5200

dburtner@quantumsails.com

Great info! Thanks Guy.

Sounds like he would make a great consultant for these proposed changes.

Bob Panico

No Regrets #1669

No Excuses # 762

Great South Bay Long Island

Haarstick was out of Rochester, NY area and bought by Quantum in 2016ish?  Doug Burtner, who has sailed on 3 national champion Ensigns, is the loft/sales manager for Quantum but started at Haarstick before time began ;)

Best,

Guy Sirois
218 Amie (Ready by Labor Day!?)

I have 3 Blade Jibs. The one that the sailing school is using is a Shore sail - so it's probably fairly old. The other 2 are Haarstick (who I have never of) and Quantum. I will put the other ones on and see if the cut is the same. I would expect in a one design class that they should be. *** But if the sail was designed for that position track, by moving the track wouldn't it make sense that the shape /cut of the sail should also changer? If we are going to - as a Class - make a change like this - I would think that we want it to be right. Let's consult with a sailmaker.

What sail maker are you using how old is it?

Zeke

Zeke - I know they are working on a solution. My concern is that the sail is not cut properly even with another track location. I've played around with moving the lead outboard and the top of the sail still did not trim properly. I would like to see the Class consult with a sailmaker before making a decision on this. Perhaps their input could improve the final outcome resulting in a more efficient sail. But the track is certainly not in the proper spot.

Bob Panico

No Regrets #1669

No Excuses #762

Great South Bay Long Island

I totally agree with all of your assessments of the Blade. It's a nice sail but the sheeting is in the wrong place. Just an FYI our commodore has put to task this issue and all I can say is it's in the works.
Hopefully in the next few months hopefully you will be hearing about the research and suggestions to come.

Zeke


Moving the track is a start but I think the cut of the sail is wrong as well. Hire a professional to re-design it.

I, too, have two Ensigns each with a blade jib.  One Ensign has roller furling and tracks for the blade jib and working jib.   The other Ensign does not have tracks for the blade jib yet because I do not want to install the tracks, only to relocate them later to be rule compliant.  This boat has a blade jib that is a year old and never used.   I am 74 and respectfully request that the Rules / Technical Committees make this decision sooner rather than later.

Both PHRF New England and ORRez handicapping have one design Ensign ratings which assumes the boat is rule compliant.

Jody Graul

Nahant MA

PLEBE YEAR – 1217

anonymous - 1637



I hope everyone has had a great summer. As some of you may know, I have been trying to get Ensign sailing going on the Great South Bay of Long Island. Our bay is pretty shallow but the 3' draft seems to be ok. We really have no mooring setups so you either have to have a slip or dry sail the boat. I have 2 Ensigns. One is dry sailed and the other one is in a slip at my Club. The boat in the water is being used for sailing lesson in our Junior Sailing Program. No motor - we sail it in and out of the slip. We use the blade Jib for lessons. It's a great concept but the sail does not trim properly. This has become an issue with the instructors. Upwind the foot is closed and shut off and the top of the sail is never full. Quite frankly it's a little embarrassing. We've tried several different lead positions, out board sheeting, a barber haul......but the sail still looks like shit! I also find it pretty hard to understand that a 60 YO design has this issue. I could see it a new boat, but you would think that after all these years a better solution would have been developed. I have no issues with my #1 or #2 genoas, which I use all the time on my other boat which I PHRF race. But these sails are bit much for young students learning how to sail. I think it's a combination of the jib leads being too far inboard and the cut of the sail. I have tried positioning the clew a little further outboard but the top of the sail still does not trim properly. The leach seems to be cut wrong. I know there is currently an effort to work on this and I am wondering where we are at with trying to correct t this problem. Does anyone have any other temporary solutions they have tried? Might I also suggest the Class utilize the services of a qualified sail maker to rectify this issue. Like it said, the sail is a great concept but it's JUST NOT RIGHT!
